HDI X01-R FRONT MOUNT INTERCOOLER KIT - TOYOTA STARLET GLANZA EP91/EP82

PRICE: $550.00
Model: IK-EP91-X01-R
Quantity:





With all HDi front mount intercoolers, The ultra high flow and efficient cooling design set a new level of performance that many other manufacturers can only try to follow.
The new released X01-R tube and fin front mount intercooler system, is specifically designed to target the ineffecient loop back design of the factory intercooler.  With the special cross fins & high flow core, the intercooler kit not only flows exceptionally well but also accommodates perfectly in the limited space within the factory front reinforcement bar and fits neatly within the factory front bumperbar.
By using a longer core length (compared to market trend),  rapid throttle response is also enhanced in its design development that means high flow and cooling efficiency with minimal turbo lag.  The piping is mandrel bent for improved flow and carefully designed to take the shortest possible route to reduce turbo lag.



CORE SIZE:
-Thickness: 100mm
-Length: 580mm
-Height: 210mm

OVERALL SIZE:
-Thickness: 100mm
-Length: 830mm
-Height: 220mm

INLET AND OUTLET PORT SIZE:
-OD: 70mm (2.75")

-Aprox weight: 7kg.


Although it is huge in size,  rapid throttle response is also kept in its design development that means high flow and cooling efficiency with minimal turbo lag.  The piping is mandrel bent for improved flow and carefully designed to take the shortest possible route to reduce turbo lag.  The BOV Port is correctly positioned and NOT on the hot pipe.



The kit comes with high quality HDi Super Clamps, HDi Silicon Hoses and a mounting kit for perfect fitment.
From the Dynapack Dyno tests there is a performance increase of 25% and capable of much more!!.




New HDI Super intercoolers, Maximum Flow, Low pressure drop, lightweight tube and fin design. Highly polished.
